Wave Soldering System TS200
The TS 200 wave soldering system, a cost effective system with many benefits.
The TS 200 can be fabricated to nearly any required application size - whether for individual, simultaneous or surface soldering. The pump unit is identical for all soldering systems, and can be exchanged quickly. A replacement pump can therefore be installed during a cleaning interval within minutes, without causing a significant interruption to the production process. The wave insert is equipped with a bayonet lock and, just like the gas hood, can be removed in only a few simple steps. If needed, the pump system can be horizontally rotated by 90°. The continuously circulating solder and permanent nitrogen gas shield guarantee an oxide-free solder wave. Thanks to its slim configuration, the TS 200 can be operated with all commonly employed soldering angles.
Benefits At a Glance:
- cost-effective purchase
- space-saving construction
- defined solder peel-off for circuit board soldering
- exceedingly maintenance-friendly
- provides outstanding solder quality
- good resistance to aggressive solders
Optionally Available:
- solder level monitoring (bar fill level)
- pneumatic solder wire feeder for 3 mm solder wire
- wave-monitoring laser
- wave-monitoring camera
- XY carriage system for fast positioning
